los Taladro magnético giratorio D1-SM tiene todas las características que convierten a la D1 en la taladradora preferida de los fabricantes, con la capacidad añadida de taladrar fácilmente agujeros en superficies convexas (diámetro mínimo de 12") y cóncavas (diámetro mínimo de 40"). Cuatro imanes giratorios individuales se ajustan a la superficie, permitiendo a la máquina trabajar en áreas de trabajo irregulares. Cada imán está equipado con características de fuerza de sujeción variable que permiten posicionar fácilmente la máquina mientras los imanes están parcialmente acoplados. Los imanes funcionan sin electricidad, lo que los convierte en una gran solución de seguridad para sus necesidades de perforación.
Especificaciones técnicas del taladro magnético portátil compacto D1
| Velocidades del motor (bajo carga): | 350 rpm |
| Fuerza de motor | 920 W 1,2 HP |
| voltaje | 115V / 60Hz o 230V / 50Hz |
| Tamaño máximo del orificio-Cortador anular | 1-7/16" (36 mm) |
| Capacidad máxima de perforación/torcido | 1/2 "(12 mm) |
| Profundidad máxima de corte | 51 mm (2 pulgadas) |
| Carrera | 70 mm (2-3/4") |
| Fuerza de sujeción magnética (superficie con un grosor de 1" (25 mm) y rugosidad Ra=1,25 | 2021,64 (lbf) 917 kgf (9000 N) |
| Dimensiones de la base magnética | 3-1/8 x 6-5/16 x 1-7/16 [“] 80 × 161 × 36,5 (mm) |
| Mín. Espesor del lugar de trabajo | 1/4 "(6 mm) |
| Huso | 3/4" (19 mm) Weldon |
| Portaherramientas | 3/4" (19 mm) Weldon |
| Peso | 22 libras (10 kg) |
Información adicional
| Peso | 34 lbs |
|---|---|
| Dimensiones | 19 × 15 × 7 en |
Application Use Cases
The S14-M suits mechanical fabrication, transportation, and construction work where angled cuts matter as much as a clean edge. It handles pipe, plate, channel, conduit, angle iron, metal studs, rebar, and tubing, making it useful for structural steel fabrication, custom metal frames, and repeatable angle cuts on production runs. Its 1750W motor and portable 72 lb frame support both jobsite work and continuous shop use.
Frequently Asked Questions
What's the difference between the S14 and S14-M?
The S14-M offers a wider +/-46° mitering range compared to the S14's 45°, plus a heavier cast-aluminum base for added stability. Both share the same 1750W motor, 14" blade, and pipe capacity, with the S14-M priced for its extra versatility.
Is 230V available, or only 120V?
The S14-M comes in both 120V/60Hz (SM-S-14-M) and 230V/50Hz (SM-S-14-M-230) versions, so it runs on standard shop power or 230V circuits depending on your facility's setup.
What blade comes included, and can it be swapped?
A newly designed 14" laser-cut TCT blade for mild steel is included. The 1" arbor bore accepts other compatible 14" blades, so operators can swap in one suited to aluminum, stainless, or thinner materials.
What's the mitering range and how is it adjusted?
The S14-M miters up to +/-46°, letting operators dial in custom angles for fabrication layouts. The precision miter table locks at the set angle, delivering repeatable, accurate cuts across a production run.
Is it suitable for field/job site use or shop-only?
At 72 lbs, the S14-M is portable enough for jobsite use while still built for shop duty. Steelmax positions it for both field and shop environments, making it a flexible pick either way.
